Performance
Capture Rate: > 99.9%
Scanning Speed: 0 – 30 km/h
Scanning Time: < 1s
Load Capacity: 20 tons
Intelligent Analysis & Comparison: Auto
Vehicle Underbody Height: 80 – 3000 mm
Vehicle Underbody Width: ≤ 4500 mm
Vehicle Underbody Length: Unlimited
System Expansion: License Plate Recognition & Face Recognition
Suspicious Object Detection: Optional
Environment
Operating Temperature: -40° C ~ +70° C
Protection Rating: IP68
Camera
Sensor Resolution: 1024P
Scan Image Resolution: ≥2000×1024
Field of View: >170°
White Balance: Auto
Auto Exposure: Auto
Power Supply
Power Input: DC24V / 150W
Network
Network Interface: Gigabit Ethernet
Protocol: IPv4
Mechanical
Dimensions: 530x337x65 (mm)
Weight: 15 kg
