Description
| Model name | 500WA |
| Display | Digital control box 7 inch |
| Detection mode | Automatic/ Infrared detection mode (4 options) |
| Maximum detection distance | 20 – 2000mm (vertical) |
| Throughput | 60 detection per min on the average. |
| Sensitivity level | 0-255 |
| Detection zone | Adjustable (Up to 93 zone) |
| Smallest metal objects detected | Φ22.25*T1.85 mm(Steel-nickel Alloy) |
| Power supply | AC 100V to 240V (DC 12V/4.2A)/ 50HZ – 60HZ |
| Operating current | 0.8A |
| Operating power | 12W |
| Operating time | 24/7 operation capability |
| Detection sound alert | 16 types of alarm tones (adjustable), 20 levels of volume (max 80 dB) |
| Detection visual indicator | 2 sets of LEDs (red) evenly distributed on left and right door panels |
| Detected contrabands | Ferrous and non-ferrous metal weapons |
| Enclosure material | Flame retardant ABS polymer, medium density fiberboard, PVC |
| Operating frequency | 0-99 |
| Waterproof | IP65 |
| Operating temperature | -20 to 65 C |
| Packaging dimensions(L*W*H) | 2330*560*785mm. |
The ProScan Global walk through metal detector 500WA is a high-performance security screening solution specifically engineered for versatility and resilience. Featuring a specialized waterproof cross-beam digital control box, this model is designed to deliver consistent, multi-zone intelligent detection even in challenging environments. With its high-definition interface and robust build, the 500WA provides an optimal balance of high sensitivity and long-term stability for professional security checkpoints worldwide.
Key technical features
- Environmental data monitoring: The system is equipped with an environmental data display function, offering high performance, high sensitivity, and excellent stability by constantly analyzing surrounding conditions.
- Networked connectivity: It supports seamless network connectivity, enabling multiple devices to be managed and monitored efficiently from a single PC.
- Smart false alarm suppression: Pre-set parameters allow for precise adjustment for the weight, volume, size, and location of metal objects. This effectively eliminates false alarms caused by personal items like keys, jewelry, and belt buckles.
- Health and media safety: The system complies with EMC electromagnetic radiation standards and utilizes low magnetic field technology. It is certified harmless to pacemaker wearers, pregnant women, and magnetically sensitive materials such as floppy disks, film, and videotapes.
- IP-rated waterproofing: The cross-beam digital control box is built to resist water and dust with IP65, ensuring reliability for semi-outdoor or high-humidity installations.
Installation condition 500WA
To ensure your device maintains peak accuracy and sensitivity, a professional walk through metal detector installation must follow these environmental requirements:
- Stable foundation: The floor must be flat and solid to prevent any vibration that could lead to “ghost” alarms.
- Metal clearance: Keep fixed metal objects at least 10cm (4 inch) away. For large moving metal objects like elevators or large gates, maintain a distance of 0.5m to 2m (20 – 79 inch).
- Interference shielding: Position the unit 0.5m to 4m (20 – 157 inch) away from electronic interference sources such as power lines, motors, or monitors.
- Frequency setting: When operating multiple units side-by-side, each device must be set to a unique working frequency to prevent mutual signal interference.
Certifications
ProScan Global is committed to global safety and quality standards. The 500WA fully meets the requirements for CE and FCC certifications, ensuring compliance with international regulations for electromagnetic compatibility and operational safety.
After-sales service system
We provide a comprehensive support network to ensure the continuous success of our clients:
- Dedicated customer care: Our post-sale support includes technical assistance to keep your security products in top condition.
- Strategic insights: As a unique value-add, ProScan Global provides clients with target market research, helping you understand local security trends and optimize your screening strategies for maximum effectiveness.
Shipping
To ensure timely delivery to our global partners, ProScan Global offers flexible logistics solutions via multiple transport modes:
- Sea freight: Cost-effective for large-scale and bulk orders.
- Air freight: Priority shipping for urgent project upgrades.
- Land transport: Reliable regional delivery for locals business.
